OPERATION

B–63444EN/01

8. DATA INPUT/OUTPUT

291

Custom macro common variables (#500 to #531) stored in the memory

of the controller can be output in the defined format to a floppy.

Outputting custom macro common variable

1 Make sure the output device is ready for output.

2 Specify the punch code system (ISO or EIA) using a parameter.

3 Press the EDIT switch on the machine operator’s panel.

4 Press function key

OFFSET

SETTING

5 Press the rightmost soft key

(next–menu key), then press soft

key

[MACRO].

6 Press soft key

[(OPRT)].

7 Press the rightmost soft key

(next–menu key).

8 Press soft keys [PUNCH] and [EXEC].

Common variables are output in the defined format.

1 Select the EDIT mode.

2 Select the tool offset data display screen by pressing

<VAR> key.

3 Press the

<WRITE> key.

4 Specify file heading when required.

For which file the offset date is output to, refer to 8.4.2.

5 While common variable is being output, the display appears as below.

>#0100=

WRITE

6 In order to stop output of data from a floppy before it has finished, turn

on external reset signal ERS (bit 7 of G008).

Once data output from a tape has been stopped, it cannot be restarted.

8.7.2

Outputting Custom

Macro Common

Variable

Procedure (CRT/MDI)

Procedure (DPL/MDI)
