OPERATION

B–63444EN/01

12. HELP FUNCTION

373

When “1. PROGRAM EDIT” is selected, for example, the screen in

Figure12 (g) is displayed.

On each

OPERATION METHOD screen, it is possible to change the

displayed page by pressing the PAGE key. The current page No. is

shown at the upper right corner on the screen.

HELP (OPERATION METHOD) 01234 N00001

<< 1. PROGRAM EDIT >> 1/4

*DELETE ALL PROGRAMS

MODE : EDIT

SCREEN : PROGRAM

OPR: (O–9999) – <DELETE>

*DELETE ONE PROGRAM

MODE : EDIT

SCREEN : PROGRAM

OPR: (O+PROGRAM NUMBER) – <DELETE>

Each item

MEM

**** *** ***

Page/maximum

page

Operation

Set mode

Operation

location

Operating

procedure

Fig.12 (g) Selected OPERATION METHOD screen

3 PARA

(OPRT)1 ALAM 2 OPR

10:00:00

S 0 T0000

5 To return to the OPERATION METHOD menu screen, press the

RETURN MENU key to display “[2 OPR]” again, and then press the [2

OPR] key again.

To directly select another

OPERATION METHOD screen on the screen

shown in Figure12 (g), enter an item No. from the keyboard and press

the

[SELECT] key.

MEM

**** *** ***

> 3

Fig.12 (h) How to select another OPERATION METHOD screen

SELECT

10:00:00

S 0 T0000

6 If you are not sure of the No. of a system parameter to be set, or to refer

to a system parameter, press the [3 PARA] key on the

HELP (INITIAL

MENU) screen. A list of parameter Nos. for each function is displayed.

(See Figure12 (i).)

It is possible to change the displayed page on the parameter screen.

The current page No. is shown at the upper right corner on the screen.

RETURN MENU key

PARAMETER TABLE

screen
