OPERATION11. SETTING AND DISPLAYING DATA

B–63444EN/01

364

1 Press the <VAR> key to display the settings screen.

2 Use the cursor keys to position the cursor at PWE.

3 Press the <1> key and the <INPUT> key, in that order, to enable

parameters to be written. The CNC unit will generate P/S alarm 100.

4 Press the <DGNOS/PARAM> key to display the parameter screen.

> &0001 00000000

&0002 00000000

5 Move the cursor to the number of the parameter to change.

Method 1

Use the cursor keys. The cursor will continue to move while a cursor

key is being pressed.

Method 2

Press the following keys and enter data in the order shown:

<No.><(parameter No.)><INPUT>

6 Enter a parameter value with the data input keys.

7 Press the <INPUT> key. The parameter value is input and displayed.

8 After all parameters have been set and confirmed, return to the

settings screen and set PWE to 0.

9 Normally, in order to release the alarm state, press the <CAN> key.

However, in order to release alarm No. 000, the power needs to be

turned off and then on again.

See Chapter 8 for setting parameters with external input/output devices

such as the Handy File.

Some parameters are not effective until the power is turned off and on

again after they are set. Setting such parameters causes alarm 000. In this

case, turn off the power, then turn it on again.

Refer to the FANUC Power Mate 0 Connection Manual (B–63443EN) for

the parameter list.

Some parameters can be set on the setting screen if the parameter list

indicates “Setting entry is acceptable”. Setting 1 for

PARAMETER

WRITE is not necessary when these parameters are set on the setting

screen.

Procedure for DPL/MDI

Explanations

D Setting parameters with

external input/output

devices

D Parameters that require

turning off the power

D Parameter list

D Setting data
