FANUC POWER MATE 0 Operators manual Page 329

Operators manual

Page of 492

/ 492

OPERATION

B–63444EN/01

9. EDITING PROGRAMS

317

Editing a program while executing another program is called background

editing. The method of editing is the same as for ordinary editing

(foreground editing).

A program edited in the background should be registered in foreground

program memory by performing the following operation:

During background editing, all programs cannot be deleted at once.

Procedure for Background Editing

1 Enter EDIT or MEMORY mode.

MEMORY mode is allowed even while the program is being

executed.

2 Press function key

PROG

3 Press soft key

[(OPRT)], then press soft key [BG–EDT].

The background editing screen is displayed (PROGRAM

(BG–EDIT) is displayed at the top left of the screen).

4 Edit a program on the background editing screen in the same way as

for ordinary program editing.

5 After editing is completed, press soft key

[(OPRT)], then press soft

key

[BG–END]. The edited program is registered in foreground

program memory.

1 Display the background edit screen by pressing the <PRGRM>

button while pressing and holding the <CAN> key.

{ }

2 Specify a program to be edited.

a) When generating a new program:

Program No. <INSERT>

<O>

b) When editing the existing program:

Program No. <↓>

<O>

3 Program edit

The program editing is the same as with the foreground program

editing operation.

{01000} ;

N10 G92 X0 ;

4 End of Background edit

It is necessary to save a program completely edited in background

into the foreground program memory.

Press the <PRGRM> button while pressing and holding the <CAN>

key.

9.7

BACKGROUND

EDITING

Procedure for CRT/MDI

Procedure for DPL/MDI
