B-65280EN/05 FANUC AC SPINDLE MOTOR αi series 2.EXPLANATION OF OPERATION MODES

- 81 -

Parameter No.

15i 16i 16i

Description

5877 5313 5313 Allowable level of position error of spindle at stop

5853

5856

5859

5862

5321 to 5324 5321 to 5324

Backlash of spindle

(16

i: No. 5322 and No. 5324 are used for the T series only.

i: No. 5324 is used for the T series only.)

3000#4 4000#4 4000#4 Reference position return direction on servo mode

3002#5 4002#5 4002#5

Whether to enable the rotation direction signal (SFR/SRV) on servo

mode

3006#7 4006#7 4006#7

Setting of the command arbitrary gear ratio function (CMR) on rigid

tapping

3016#4 4016#4 4016#4

Setting related to the control characteristics on Cs contouring control or

servo mode

- - 4037 Velocity loop feed-forward coefficient

3044

3045

4044

4045

4044

4045

Velocity loop proportional gain on servo mode/spindle synchronous

control

(It is selected by input signal CTH1A/B.)

3052

3053

4052

4053

4052

4053

Velocity loop integral gain on servo mode/spindle synchronous control

(It is selected by input signal CTH1A/B.)

3056 to 3059 4056 to 4059 4056 to 4059

Gear ratio between spindle and motor

(It is selected by input signal CTH1A or CTH2A)

3065 to 3068 4065 to 4068 4065 to 4068

Spindle position gain on servo mode/spindle synchronous control

(It is selected by input signal CTH1A or CTH2A)

3073 4073 4073 Grid shift amount on servo mode

3074 4074 4074 Reference position return speed on Cs contouring control/servo mode

3091 4091 4091

Position gain change ratio at reference position return time on servo mode

3085 4085 4085

Motor voltage (for high-speed characteristics) on servo mode/spindle

synchronous control

3137 4137 4137

Motor voltage (for low-speed characteristics) on servo mode/spindle

synchronous control

3099 4099 4099 Delay time for stable motor excitation

3171

3173

4171

4173

4171

4173

Denominator of an arbitrary gear ratio between the motor sensor and

spindle

(A parameter is selected by the input signal CTH1A.)

3172

3174

4172

4174

4172

4174

Numerator of an arbitrary gear ratio between the motor sensor and

spindle

(A parameter is selected by the input signal CTH1A.)

- -

4344

Advanced preview feed-forward coefficient

NOTE

1 For the parameters related to detectors, see Section

1.3 “PARAMETERS RELATED TO DETECTORS”

in the Part I.

2 For velocity loop proportional/integral gain

adjustment, see Section 4.1, "VELOCITY LOOP

GAIN ADJUSTMENT", in Part I.
