1.START-UP FANUC BUILT-IN SPINDLE MOTOR Bis series B-65280EN/05

- 500 -

1.5 MAGNETIC POLE DETECTION

1.5.1 Overview

To control the synchronous built-in spindle motor, information about

the magnetic pole position (phase) of the rotor is needed. Operation

for detecting the magnetic pole position (phase) of the rotor is referred

to as magnetic pole detection. Immediately after the power is turned

on or if magnetic pole position information is lost for a cause such as

an alarm, magnetic pole detection needs to be performed before the

motor can be driven.

Two magnetic pole detection modes are available:

• Automatic mode (usable with 9D53/C edition or later and

9D70/B edition or later)

• Direct current activation mode

By setting the phase difference between the magnetic pole position

(phase) of the rotor and the one-rotation signal generation position

beforehand in a parameter, control can be exercised using a

parameter-set offset value and one-rotation signal position as

reference data after one-rotation signal detection (AMR offset

function).
