1.START-UP FANUC BUILT-IN SPINDLE MOTOR Bis series B-65280EN/05
- 508 -
15i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
3398 4398 4398
SELMET
SELMET Selects a magnetic pole detection mode.
0 : Performs magnetic pole detection in the direct current activation
mode.
1 : Performs magnetic pole detection in the automatic mode.
NOTE
This parameter is valid with 9D53 Series C (03)
edition or later and 9D70 series B (02) edition or
later.
15i 16i 30i
3449 4449 4449
Direction detection current/polarity determination current
The upper three digits (ten thousands, thousands, and hundreds)
indicate a direction detection current, and the lower two digits (tens
and ones) indicate a polarity determination current.
Usually, this parameter need not be adjusted. (Set 0.)
Direction detection current (upper three digits)
Unit of data : 1%
Valid data range : 0 to 320
Standard setting value : 0
Set a current for magnetic pole direction detection in magnetic pole
detection operation. When 0 is set, 100% is set.
The guideline for setting when the detection current is about 3 A with
an inductance of 2.7 mH (5.3 mH) at 200 V (400 V) is 100%.
This parameter is valid in the automatic mode.
Polarity determination current (lower two digits)
Unit of data : 1%
Valid data range : 0 to 99
Standard setting value : 0
Set a detection current for determining the polarity of the magnetic
pole as a ratio to the maximum current value. When 0 is set, 70% is
set internally.
This parameter is valid in the automatic mode.
NOTE
This parameter is valid with 9D53 Series C (03)
edition or later and 9D70 series B (02) edition or
later.
