B-65280EN/05 FANUC BUILT-IN SPINDLE MOTOR Bis series 2.EXPLANATION OF OPERATION MODES
- 517 -
2.1.5 Related Parameters
Parameter No.
15i 16i 30i
Description
3705#0 3705#0 Sets SF signal output and the S code for an S command.
3705#2 3705#2 Gear switch method (M series only)
3705#4 3705#4 Sets SF signal output and the S code for an S command (T series only).
3705#5 3705#5
Sets SF signal output when constant surface speed control is exercised
and an S code is specified (M series only).
3705#6 3705#6 Sets SF signal output (M series only).
3706#4 3706#4 Spindle gear selection method (M series only)
3706#7,#6 3706#7,#6 Spindle speed command polarity (valid when input signal SSIN = 0)
3709#0 3709#0
Number of sampling operations at spindle speed calculation time (T
series only for 16i)
3735 3735 Minimum clamp speed of the spindle motor (M series only)
3736 3736 Maximum clamp speed of the spindle motor (M series only)
3740 3740 Time until the spindle speed arrival signal is checked
3741 3741 Maximum spindle speed for gear 1
3742 3742 Maximum spindle speed for gear 2
3743 3743 Maximum spindle speed for gear 3
3744 3744 Maximum spindle speed for gear 4 (T series only)
3751 3751
Spindle motor speed at the switch point between gear 1 and gear 2 (M
series only)
3752 3752
Spindle motor speed at the switch point between gear 2 and gear 3 (M
series only)
3772 3772 Maximum allowable spindle speed
2031 3031 3031 Allowable number of S code characters
2003#1 Sets an S code polarity.
2204#0 Sets the display of an actual spindle speed.
2402#6 Sets the S code specified in a block containing G92.
5602#3
Whether to provide an indication for an alarm detected with the spindle
amplifier. (Set "0" usually.)
5611
Number of sampling operations when an average spindle speed is to be
found.
5612 Unit of spindle speed output with the DO signal
5807#0
Enables/disables the spindle alarms (SPxxxx) of all spindles. (Set "0"
usually.)
5842 3720 Number of position coder pulses
5847 3721
Number of gear teeth on the position coder side on velocity control (for
feed per revolution, threading, etc.)
5848 3722
Number of gear teeth on the spindle side on velocity control (for feed per
revolution, threading, etc.)
5850 Spindle number to be selected at power-on/reset time
5820#4 Sets the method of spindle speed calculation.
3006#5 4006#5 4006#5 Sets an analog override range.
3009#4 4009#4 4009#4
Whether to output the load detection signals (LDT1, LDT2) during
acceleration/deceleration
3009#6 4009#6 4009#6 Analog override type
3012#6 4012#6 4012#6 Sets whether to drive the synchronous built-in spindle motor. (Set "1".)
3012#7 4012#7 4012#7 Sets the spindle HRV function. (Set "1".)
5607#0 4019#7 4019#7 Automatic spindle parameter setting function
3352#1 4352#1 4352#1 Sets the peak hold function for load meter output.
