B-65280EN/05 FANUC AC SPINDLE MOTOR αi series 2.EXPLANATION OF OPERATION MODES

- 35 -

Parameter No.

15i 16i 30i

Description

3009#6 4009#6 4009#6 Analog override type

3012#7 4012#7 4012#7 Sets the spindle HRV function. (Set "1".)

5607#0 4019#7 4019#7

Automatic spindle parameter setting function

3352#1 4352#1 4352#1 Sets the peak hold function for load meter output.

3020 4020 4020 Maximum motor speed

3022 4022 4022 Speed arrival detection level

3023 4023 4023 Speed detection level

3024 4024 4024 Speed zero detection level

3025 4025 4025 Sets a torque limitation value.

3026 4026 4026 Load detection level 1

3027 4027 4027 Load detection level 2

3028 4028 4028 Sets an output limitation pattern.

3029 4029 4029 Output limitation value

3030 4030 4030 Soft start/stop setting time

3040

3041

4040

4041

4040

4041

Velocity loop proportional gain on the velocity control mode

(A parameter is selected by the PMC input signal CTH1A.)

3048

3049

4048

4049

4048

4049

Velocity loop integral gain on the velocity control mode

(A parameter is selected by the PMC input signal CTH1A.)

3056 to 3059 4056 to 4059 4056 to 4059

Spindle and motor gear ratio data

(A parameter is selected by the PMC input signals CTH1A and CTH2A.)

3081 4081 4081 Delay time until the motor power is turned off

3082 4082 4082 Sets an acceleration/deceleration time.

3083 4083 4083 Motor voltage on the velocity control mode

3136 4136 4136 Motor voltage on the velocity control mode (for low-speed characteristics)

3171

3173

4171

4173

4171

4173

Denominator of an arbitrary gear ratio between the motor sensor and

spindle

(A parameter is selected by the input signal CTH1A.)

3172

3174

4172

4174

4172

4174

Numerator of an arbitrary gear ratio between the motor sensor and spindle

(A parameter is selected by the input signal CTH1A.)

3508 4508 4508 Rate of change in acceleration at soft start/stop

NOTE

1 For the detector-related parameters, see Section

1.3, "PARAMETERS RELATED TO DETECTORS",

in Part I.

2 For velocity loop proportional/integral gain

adjustment, see Section 4.1, "VELOCITY LOOP

GAIN ADJUSTMENT", in Part I.
