AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 683

Parameter manual
B-65280EN/05 APPENDIX A.SPINDLE PARAMETER TABLE
- 659 -
Internal
data No.
F-xxx
15i 16i 30i
bit
Standard
initial setting
data
Contents Classification
Reference
item
154 3162 4162 4162 0 Integral gain of velocity loop during cutting feed on Cs
contouring control mode (High)
B ΙV-2.4.7
155 3163 4163 4163 0 Integral gain of velocity loop during cutting feed on Cs
contouring control mode (Low)
B ΙV-2.4.7
161 3169 4169 4169 Depends on
the model
Temperature monitoring time constant
C ΙV-2.6.4
162 3170 4170 4170 0 Current overload alarm detection level
D ΙV-2.6.4
163 3171 4171 4171 0 Denominator of arbitrary gear ratio between motor sensor
and spindle (High)
A ΙV-1.3.2
164 3172 4172 4172 0 Numerator of arbitrary gear ratio between motor sensor
and spindle (High)
A ΙV-1.3.2
165 3173 4173 4173 0 Denominator of arbitrary gear ratio between motor sensor
and spindle (Low)
A ΙV-1.3.2
166 3174 4174 4174 0 Numerator of arbitrary gear ratio between motor sensor
and spindle (Low)
A ΙV-1.3.2
230 3248 4248 4248 0 Spindle load monitor torque constant
B ΙV-5.7.5
231 3249 4249 4249 0 Spindle load monitor observer gain 1
B ΙV-5.7.5
232 3250 4250 4250 0 Spindle load monitor observer gain 2
B ΙV-5.7.5
304 3320 4320 4320 0 Motor acceleration at deceleration time (High)
B ΙV-5.4.6
305 3321 4321 4321 0 Motor acceleration at deceleration time (Medium High)
B ΙV-5.4.6
306 3322 4322 4322 0 Motor acceleration at deceleration time (Medium Low)
B ΙV-5.4.6
307 3323 4323 4323 0 Motor acceleration at deceleration time (Low)
B ΙV-5.4.6
310 3326 4326 4326 0 Acceleration limitation start speed at deceleration time
(High)
B ΙV-5.4.6
312 3328 4328 4328 0 Command multiplication for spindle orientation by position
coder
B ΙV-5.3.6
314 3330 4330 4330 0 Acceleration limitation start speed at deceleration time
(Low)
B ΙV-5.4.6
318 3334 4334 4334 0 Number of motor sensor arbitrary teeth
A ΙV-1.3.2
320 3336 4336 4336 0 Switching point used for an acceleration/deceleration time
constant used for spindle synchronous control
B ΙV-2.5.8
324 3340 4340 4340 0 Bell-shaped acceleration/deceleration time constant during
spindle synchronous control
B ΙV-2.5.8
325 3341 4341 4341 0 Unexpected disturbance torque detection level
B ΙV-5.7.5
328 3344 4344 4344 0 Advanced preview feed-forward coefficient
B ΙV-5.6.4
329 3344 4345 4345 0 Spindle motor speed specification detection level
B ΙV-2.6.4
330 3346 4346 4346 0 Incomplete integration factor
B
ΙV-2.5.8
ΙV-2.6.4
335 3351 4351 4351 0 Current detection offset compensation
B ΙV-2.6.4
336H 3352 4352 4352 #1 0 Setting of the peak hold function for load meter output
B ΙV-2.1.6
#4 0 Setting of whether to enable/disable feed forward at all
times
B ΙV-5.8.8
#6 0
Inter-SPM communication slave axis setting B ΙV-5.8.8
#7 0
Inter-SPM communication master axis setting B ΙV-5.8.8
338 3355 4355 4355 0 Motor sensor signal amplitude ratio compensation
A
ΙV-1.3.2
ΙV-4.3
339 3356 4356 4356 0 Motor sensor signal phase difference compensation
A
ΙV-1.3.2
ΙV-4.3
345 3362 4362 4362 0 Load meter compensation 1
C ΙV-2.6.3
346 3363 4363 4363 0 Load meter compensation 2
C ΙV-2.6.3
347 3364 4364 4364 0 Load meter compensation 3
C ΙV-2.6.3
352 3369 4369 4369 0 Spindle synchronous orientation deceleration coefficient
B ΙV-5.5.6
366 3384 4384 4384 0 Spindle EGB : Maximum acceleration/deceleration value in
automatic phase matching
B ΙV-5.8.8
367 3385 4385 4385 0 Spindle EGB : time constant for free-running phase
matching
B ΙV-5.8.8
368 3386 4386 4386 0 Spindle EGB : master side detector pulse count
B ΙV-5.8.8
369 3387 4387 4387 0 Spindle EGB : synchronous ratio numerator
B ΙV-5.8.8
370 3388 4388 4388 0 Spindle EGB : synchronous ratio denominator
B ΙV-5.8.8
