B-65280EN/05 FANUC AC SPINDLE MOTOR αCi series 2.EXPLANATION OF OPERATION MODES

- 419 -

15i 16i 30i

3081 4081 4081

Delay time until the motor power is turned off

Unit of data : 10ms

Valid data range : 0 to 1000

Standard setting value : 20(200ms)

If SFRA = 0 or SRVA = 0 is specified, this parameter sets a period of

time from the stop of the motor (detection of the speed zero detection

signal SSTA = 1) until the power to the motor is turned off.

NOTE

When a small value is set in this parameter, the

motor can coast after the power to the motor is

turned off.

15i 16i 30i

3082 4082 4082

Setting of acceleration/deceleration time

Unit of data : 1sec

Valid data range : 0 to 255

Standard setting value : 10

This parameter sets a period of time in which alarm detection is

disabled by assuming that the spindle motor is being accelerated or

decelerated even if the velocity error exceeds the velocity error excess

alarm (SPM alarm 02) level after start of acceleration/deceleration on

the velocity control mode.

In the velocity control mode, a step-by-step speed command is

specified. So, the spindle motor cannot follow up the command

immediately after start of acceleration/deceleration, and the velocity

error exceeds the velocity error excess alarm level. This parameter is

used to prevent the velocity error excess alarm (SPM alarm 02) from

being detected incorrectly immediately after start of

acceleration/deceleration.

NOTE

With a machine tool such as a lathe that has a large

load inertia, the acceleration/deceleration time

becomes longer. In such a case, set the value

corresponding to the acceleration/deceleration time

of the machine in this parameter.

15i 16i 30i

3083 4083 4083

Motor voltage setting on velocity control mode

Unit of data : 1%

Valid data range : 0 to 100

Standard setting : 60

This parameter is used to set a motor voltage on velocity control mode.

Usually, this parameter need not be adjusted. Use the standard setting.
