B-65280EN/05 FANUC BUILT-IN SPINDLE MOTOR Bis series 2.EXPLANATION OF OPERATION MODES

- 541 -

(2) Spindle data used for adjustment

Adjust the parameters while observing the motor speed, torque

command, velocity error, synchronous error, and other waveform by

using a spindle check board and oscilloscope or SERVO GUIDE. The

table below lists spindle check board settings for observing the

waveform.

Check board setting address

Output to CH1 Output to CH2

Settings Observing data

d-05 d-09 25

d-06 d-10 12

d-07 d-11 0

d-08 d-12 1

Velocity error

±128 min

-1

at ±5 V

±256min

-1

at ±5 V if d-06 (d-10) is set to 13

d-05 d-09 90

d-06 d-10 7

d-07 d-11 0

d-08 d-12 1

Torque command

Maximum positive/negative torque command at ±5 V

Maximum positive/negative torque command at ±2.5 V

if d-06 (d-10) is set to 8

d-05 d-09 68

d-06 d-10 0

d-07 d-11 0

d-08 d-12 1

Synchronous error (value converted for the spindle:

4096 pulses/rev)

±128 pulses at ±5 V

±256 pulses at ±5 V if d-06 (d-10) is set to 1

±512 pulses at ±5 V if d-06 (d-10) is set to 2

d-05 d-09 19

d-06 d-10 18

d-07 d-11 0

d-08 d-12 1

Motor speed

±8192 min

-1

at ±5 V

±4096 min

-1

at ±5 V if d-06 (d-10) is set to 17

±2048 min

-1

at ±5 V if d-06 (d-10) is set to 16

NOTE

When observing the synchronous error of Series 16i, set the

following parameters:

No. 3700, #7 = 1:

Uses the synchronous error output (maintenance function).

(Return the setting to 0 after the observation is completed.)

No. 5203, #7 = 1 :

Sets a synchronous error update cycle.

(Return the setting to 0 after the observation is completed.)

No. 5204, #0 = 0 :

Displays the synchronous error on the diagnosis screen.
