D.LISTS OF ALARMS/STATE ERRORS APPENDIX B-65280EN/05

- 684 -

D.1 LIST OF SPINDLE ALARMS

This section provides a list of spindle alarms. For details of the alarms

and actions to be taken, refer to Part II, "TROUBLESHOOTING", in

"FANUC SERVO MOTOR αi series MAINTENANCE MANUAL

(B-65285EN)".

Alarm No. LED display

15i 16i 30i SPM PSM

Description

SP097x 749 SP12xx A Program ROM error

SP097x 749 SP12xx A1 Program ROM error

SP097x 749 SP12xx A2 Program ROM error

SP0001 9001 SP9001 01 Motor overheat

SP0002 9002 SP9002 02 Excessive velocity error

SP0003 9003 SP9003 03 DC link fuse blown

SP0004 9004 SP9004 04 E Open phase in the converter main power supply

SP0006 9006 SP9005 06 Temperature sensor disconnected

SP0007 9007 SP9006 07 Overspeed

SP0009 9009 SP9009 09 Main circuit overload/IPM overheat

SP0011 9011 SP9011 11 7 Converter: DC link overvoltage

SP0012 9012 SP9012 12 DC link overcurrent/IPM alarm

SP098x 750 SP12xx 13 CPU internal data memory error

SP0015 9015 SP9015 15 Speed range switching/spindle switching alarm

SP0016 9016 SP9016 16 RAM error

SP098x 750 SP12xx 18 Program sum check error

SP098x 750 SP12xx 19 Excessive offset of the phase U current detection circuit

SP098x 750 SP12xx 20 Excessive offset of the phase V current detection circuit

SP0021 9021 SP9021 21 Position sensor polarity setting incorrect

SP022x 749 SP12xx 24 Serial communication error

SP0027 9027 SP9027 27 Position coder disconnected

SP0029 9029 SP9029 29 Short-time overload

SP0030 9030 SP9030 30 1 Overcurrent in the converter input circuit

SP0031 9031 SP9031 31 Motor lock alarm

SP0032 9032 SP9032 32 Serial communication LSI RAM error

SP0033 9033 SP9033 33 5 Converter: DC link precharge failure

SP0034 9034 SP9034 34 Parameter data out of the specifiable range

SP0035 9035 SP9035 35 Gear ratio parameter error

SP0036 9036 SP9036 36 Error counter overflow

SP0037 9037 SP9037 37 Speed detector parameter error

SP0041 9041 SP9041 41 Position coder one-rotation signal detection error

SP0042 9042 SP9042 42 Position coder one-rotation signal not detected

SP0046 9046 SP9046 46

Position sensor one-rotation signal detection error during

thread cutting

SP0047 9047 SP9047 47 Position coder signal error

SP0050 9050 SP9050 50

Excessive speed command calculation value during

spindle synchronous control

SP0051 9051 SP9051 51 4 Converter: DC link low voltage

SP0052 9052 SP9052 52 ITP signal error I

SP0053 9053 SP9053 53 ITP signal error II

SP0054 9054 SP9054 54 Current overload alarm

SP0055 9055 SP9055 55 Abnormal switching status of power leads
