3.SELECTING A MOTOR SPECIFICATIONS FOR THE αiS/αi SERIES B-65262EN/03

- 54 -

[Example of calculation for condition 4-1] Example of calculation

Try to perform linear acceleration/deceleration under the

following condition.

=3000 [min

-1

]

=0.1 [s]

=30 [s

-1

]

=0.01412 [kg⋅m

]

Select the α22/4000is provisionally selected in example of

calculation <1>.

motor inertia is 0.0053 [kg⋅m

] when α22/4000is is selected,

so the load inertia is calculated as follows:

= 3000×(2π/60)×(1/0.08)×(0.0053+0.01412÷0.9)×(1-e

-30×0.08

)

=74.9[N⋅m]=765[kgf⋅cm]

= 3000×{1-1/(0.1×30)×(1-e

-30×0.1

)}=2050[min

-1

]

Acceleration torque in feed-forward during rapid traverse + bell-shaped

acceleration/deceleration

Torque

Speed

Time

Speed

Specified speed and actual

speed (nearly coincide with

each other)

Time

cceleration

Acc

Point at which the

maximum torque is

required

When the feed-forward coefficient is large enough, the acceleration

torque in feed-forward during rapid traverse + bell-shaped

acceleration/deceleration can approximate to the value obtained with

the feed-forward coefficient = 1. When the feed-forward coefficient is

1, the equations for calculating the acceleration torque (T

), speed

), and maximum workpiece acceleration (Acc

) are given below:
