B-65262EN/03 SPECIFICATIONS FOR THE αiS/αi SERIES 3.SELECTING A MOTOR

- 59 -

[Example of calculation for condition 5]

Root-mean-square value of the torques

Example)

α30/4000i

S ( T

= 3.0[N⋅m] = 306[kgf⋅cm] ), T

= 83.2[N⋅m],

= T

= 3.0[N⋅m], t

= 0.08[sec], t

= 2.0[sec], t

= 3.0[sec]

() ()

30.220.08

30.30.083.0-83.22.00.30.080.32.83

++×

×+×+×+×+

rmsT

= 15.0[N⋅m] < T

× 0.9 = 30 × 0.9 = 27[N⋅m]

The α30/4000is can be used for operation.

Root-mean-square value of torque in a cycle in which the load varies

If the load conditions (cutting load, acceleration/deceleration

conditions, etc.) vary widely in a single cycle, write a time-torque

graph according to the operation cycle, as in above item. Obtain the

root-mean-square value of the torques and check that the value is

smaller than or equal to the torque at stall.

332211

...

222

tTtTtTtT

rms

++++

= t

+ t

+. . . + t

NOTE

The motor actually rotates, but the determination

must be based on the stall torque.

When the motor is being operated at high speed for

a comparatively large proportion of the time, you

must take the rotating speed of the motor into

consideration and evaluate whether output can be

specified in terms of a continuous operation torque.
