Conversional Automatic Programming (CAP) Operators manual Page 149

Operators manual
PROGRAMMING AND
OPERATION BY SYMBOLIC FAPT
B–61804E–2/05
3. EXECUTION OF
SYMBOLIC FAPT
138
WARNING
Even when the tool path and machining processes
specified in NC data are verified by machining simulation or
tool path check, if the data relating to the actual tool offset
and workpiece shift is incorrect, the tool may collide with the
workpiece and/or machine, possibly causing damage to the
machine and/or tool itself, or injury to the user. Before
starting a production run, perform a dry run to ensure that
the tool will not collide with the workpiece or machine. For
example, specify a low feedrate, then start the NC program
without mounting a workpiece on the machine.
Select
5
on the menu screen to display the NC data generation screen.
Horizontal lathe
Vertical lathe
3.5
NC DATA
PREPARATION
3.5.1
Preparations of NC
Data and Registrations
of Machining Memory
