Conversional Automatic Programming (CAP) Operators manual Page 709

Operators manual
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
APPENDIX
59
(h)Value 0 code output
When the least significant 1 digit (major classification) is 7 ...
***7;
Most significant
3 digits (detailed
classification)
Least significant
1 digit (major
classification)
Function Remarks
0 0 0 7 Z0 output The first character
address of MTF 1040
0 1 0 7 W0 output The second character
address of MTF 1040
1 0 0 7 X0 The first character
address of MTF 1041
1 1 0 7 U0 The second character
address of MTF 1041
3 0 0 7 R0 The first character
address of MTF 1042
3 1 0 7 R0 The second character
address of MTF 1042
4 0 0 7 R0 The first character
address of MTF 1043
4 1 0 7 R0 The second character
address of MTF 1043
6 0 0 7 F0 The first character
address of MTF 1044
6 1 0 7 F0 The second character
address of MTF 1044
7 0 0 7 F0 The first character
address of MTF 1045
7 1 0 7 F0 The second character
address of MTF 1045
8 0 0 7 C0 output The first character
address of MTF 1300
8 1 0 7 H0 output The second character
address of MTF 1300
