Conversional Automatic Programming (CAP) Operators manual Page 170

Operators manual
B–61804E–2/05
3. EXECUTION OF
SYMBOLIC FAPT
PROGRAMMING AND
OPERATION BY SYMBOLIC FAPT
159
(8)Setting other data
This function causes no addition to, or modification of, the setting of
the material data and tooling information.
*** The threading methods that can be used depend on the NC
specifications. ***
15–TFB 16–T CAP II
(Threading method 1)
Cutting using one cutting edge and a
constant cutting amount
f f
G92
(Threading method 2)
Alternate cutting using two cutting edges
and a constant cutting amount
f f
G32
(Threading method 3)
Cutting using one cutting edge and a
constant depth of cut
f f
(Threading method 4)
Alternate cutting using two cutting edges
and a constant depth of cut
f f
(Threading method 1)
Cutting using one cutting edge and a
constant cutting amount
f f
G76
(Threading method 2)
Alternate cutting using two cutting edges
and a constant cutting amount
f
G76
(Threading method 3)
Cutting using one cutting edge and a
constant depth of cut
f
(Threading method 4)
Alternate cutting using two cutting edges
and a constant depth of cut
f
