Conversional Automatic Programming (CAP) Operators manual Page 699

Operators manual
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
APPENDIX
49
Parameter No. RemarksMeaning
2200 Start part of C–axis machining
2201 End part of C–axis machining
2202 Setting of coordinate system for C–axis machining, Tool selection
T code output
2203 Drill cycle (G81, G82)
Command block output – Part 1
G81 is output when the dwell time is 0
2204 Drill cycle (G81, G82)
Command block output – Part 2
G82 is output when the dwell time is
other than 0
2205 Peck drilling cycle (G83),
High–speed peck drilling cycle (G83.1),
Command block output – Part 1
Machining type
2: G83.1
3: G83
2206 Peck drilling cycle (G83),
High–speed peck drilling cycle (G83.1),
Command block output – Part 2
2207 Tapping cycle (G84),
Reverse tapping cycle (G84.1),
Command block output – Part 1
In the case of reverse screw: G84.1 is
output
2208 Tapping cycle (G84),
Reverse tapping cycle (G84.1),
Command block output – Part 2
2209 Start of cylindrical interpolation
2210 End of cylindrical interpolation
2211 Spindle indexing command block output
2212 Block in which cutter compensation for front milling (polar
coordinate interpolation) or finishing of Y–axis pattern/contouring
is started
Valid when bit 7 of MTF 1305 is set to
1
2213 Block in which cutter compensation for front milling (polar
coordinate interpolation) or finishing of Y–axis pattern/contouring
is canceled
2214 Cylindrical interpolation start block
2215 Cylindrical interpolation cancellation block
2216 Boring cycle block (G85, G89) 1
2217 Boring cycle block 2
2220 Start of C–axis center drilling (Only for 5900 and 5F00 systems)
2221 Start of C–axis drilling (Only for 5900 and 5F00 systems)
2222 Start of C–axis tapping (Only for 5900 and 5F00 systems)
2223 Start of C–axis grooving (Only for 5900 and 5F00 systems)
2224 Start of C–axis notching (Only for 5900 and 5F00 systems)
2225 Start of C–axis cylindrical grooving (Only for 5900 and 5F00 systems)
