Conversional Automatic Programming (CAP) Operators manual Page 682

Operators manual
APPENDIX
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
32
Parameter
No.
RemarksDescription
Initial
value
Format
0751 Real number
3. mm specification
Tip width of the drilling tool.
Unit: mm or inch
0.1 inch specification
Unit:
mm
or
inch
0752 Real number
3. mm specification
Tip width of the grooving tool.
Unit: mm or inch
Parameters
for
0.1 inch specification
Unit:
mm
or
inch
for
animated
drawing
0753 Real number
2. mm specification
Tip width of the threading tool.
Unit: mm or inch
drawing
0.08 inch specification
Unit:
mm
or
inch
0754 Real number
5. mm specification
Tip width of the general–purpose tool.
Unit: mm or inch
0.2 inch specification
Unit:
mm
or
inch
0755 Real number
0.2 mm specification
Initial value of the fine chamfering amount.
Unit: mm or inch
0.008 inch specification
Unit:
mm
or
inch
0756 Real number 120 Max. angle in which fine chamferring is performed. (Setting
range 0°< Angle to 180°)
0757 Real number 1.5 Delay amount of tool 2 with respect to tool 1 during balance
cutting (type B), Unit: rev
15–TTFB
only
0758 to
0768
0, 1
designation (8 bits)
Undefined Can’t use. (Don’t change the data.)
0769 Real number 0.8 Can’t use. (Don’t change the data.)
0770 Character Undefined File name of the sub cycle file using the automatic loading Max. 15
characters.
0771 Character Undefined Axis names and their order (Specify the axis names in the order
in which they are programmed on the NC. Example: XZCY)
0771 to
0776
0, 1
designation (8 bits)
Undefined Can’t use. (Don’t change the data.)
NOTE
The undefined character parameter is indicated with the “D”
code. To return to undefined data after setting data at the
undefined parameter No.0016, 0017, input two or more SP
codes. In this case, instead of the “D” code, a space is
displayed on the CRT. To change the undefined parameter
to undefined data, input
and .
DEL
INPUT
