Conversional Automatic Programming (CAP) Operators manual Page 542

Operators manual
Y–AXIS FAPT FUNCTION
B–61804E–2/05
6. SYSTEM PARAMETERS
278
Parameter No. RemarksDescriptionInitial valueFormat
0412
0, 1
designation
(8 bits)
00000000
Single step of Y–axis tapping process (refer to the
parameter No.410)
0413
0, 1
designation
(8 bits)
00000000
Single step of Y–axis pattern machining process (refer
to the parameter No.410)
0414
0, 1
designation
(8 bits)
00000000
Single step of Y–axis contouring process (refer to the
parameter No.410)
0415 to 0419
0, 1
designation
(8 bits)
00000000
Can’t use.
(Don’t change the data.)
0420
Real number
2.
mm specification
Clearance amount (C1) of Y–axis
center drilling
0420
Real
number
0.08
inch specification
center
drilling
Unit: mm or inch
0421 Real number Undefined
Can’t use.
(Don’t change the data.)
0422
Real number
2.
mm specification
Clearance amount (C1) of Y–axis
drilling (machining method 1)
0422
Real
number
0.08
inch specification
drilling
(machining
method
1)
Unit: mm or inch
0423
Real number
2.
mm specification
Clearance amount (C2) of Y–axis
drilling (machining method 1)
0423
Real
number
0.08
inch specification
drilling
(machining
method
1)
Unit: mm or inch
0424 Real number Undefined
Can’t use.
(Don’t change the data.)
0425
Real number
2.
mm specification
Clearance amount (C1) of Y–axis
drilling (machining method 2)
0425
Real
number
0.08
inch specification
drilling
(machining
method
2)
Unit: mm or inch
0426
Real number
2.
mm specification
Clearance amount (C2) of Y–axis
drilling (machining method 2)
0426
Real
number
0.08
inch specification
drilling
(machining
method
2)
Unit: mm or inch
0427
Real number
2.
mm specification
Cutting depth (D1) of Y–axis
drilling (machining method 2)
0427
Real
number
0.08
inch specification
drilling
(machining
method
2)
Unit: mm or inch
0428
Real number
2.
mm specification
Return relief amount (U) of
C–axis drilling (machining
0428
Real
number
0.08
inch specification
method 2)
Unit: mm or inch
0429 Real number Undefined
Can’t use.
(Don’t change the data.)
0430
Real number
2.
mm specification
Clearance amount (C1) of Y–axis
drilling (machining method 3)
0430
Real
number
0.08
inch specification
drilling
(machining
method
3)
Unit: mm or inch
0431
Real number
2.
mm specification
Clearance amount (C2) of Y–axis
drilling (machining method 3)
0431
Real
number
0.08
inch specification
drilling
(machining
method
3)
Unit: mm or inch
