Conversional Automatic Programming (CAP) Operators manual Page 693

Operators manual
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
APPENDIX
43
Parameter
No.
Description
Initial
value
Format
1240 Integer 4 Dwell G code
1241 Integer 28 Not used
1242 Integer 29 Not used
1243 Integer 30 Not used
1244 Integer 50 Coordinate system setting G code
1245 Integer 70 Not used
1246 Integer 71 Not used
1247 Integer 72 Not used
1248 Integer 73 Not used
1249 Integer 74 Not used
1250 Integer 75 Not used
1251 Integer 76 Not used
1252 Integer 54 First spindle side workpiece coordinate system select G code
1253 Integer 55 Second spindle side workpiece coordinate system select G code
1260 Integer 98 Per minute feed G code
1261 Integer 99 Per revolution feed G code
1262 Integer –1 G code for return to the initial point (only for 5E00, 5710 series)
1300 Two characters CH C–axis command address
1st character: Absolute command
2nd character: Incremental command
1301 Real number 0.001 C–axis lease input increment (Deg)
1302 Integer 3 No. of digits to the right of decimal point of C–axis least input increment.
1303 Real number 4000. C–axis rapid traverse rate (Deg/min)
1304 0, 1
designation (8 bits)
00000011 Drilling canned cycle in each process (C–axis/Y–axis)
0 : Not used.
1 : Used.
Center drilling
Drilling
1305 Specified with 0 or
1 (8 bits)
00000000
Bit 0 IN front notching, finishing of Y–axis pattern machining, and
contouring, cutter compensation is carried out by:
0 : FAPT (G40, G41, and G42 are not output.)
1 : NC (G40, G41, and G42 are output.)
Bit 1 Specifies whether the radius command for cylindrical interpolation is
output with a decimal point.
0 : No decimal point
1 : With a decimal point
7
0
6
0
5
0
4
0
3
0
2
0
1 0Bit
