Conversional Automatic Programming (CAP) Operators manual Page 680

Operators manual
APPENDIX
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
30
Parameter
No.
RemarksDescription
Initial
value
Format
0708 0, 1
designation (8 bits)
00000000
Bit 0 Common data to be restored when the power is turned
on
0 : System parameters
1 : Family data
Bit 2 Specifies whether process names are automatically
inserted for each process when an NC data is created.
0 : No process name is automatically inserted.
1 : Process names are automatically inserted.
Bit 3 Specifies whether the initial screen display function is
used.
0 : Not used
1 : Used
Bit 4 Input/output format of material data and tooling
information
0 : Binary
1 : ISO/EIA
Bit 5 Initial screen at Power up.
0 : FAPT side
1 : NC side
Bit 6 Automatic process setting screen display
0 : High–speed type (The screen is skipped.)
1 : Conventional type (The screen is not skipped.)
Bit 7 Specify whether back machining is performed.
0 : Not performed
1 : Performed
7 6 5 4 3 2 1
0
0Bit
0709 0, 1
designation (8 bits)
10000000 Bit 4 When the cutting end point is on a blank
0 : The tool retracts to the minimum diameter of the
blank.
1 : The tool retracts in the Z axis direction.
Bit 5 Prompt for “CUTTING ANOTHER AREA BY SAME
TOOL? ... CN=”
0 : Displayed on the cutting condition setting screen.
1 : Displayed on the CN setting screen.
Bit 7 On the machining procedure setting screen,
0 : The machining procedure data cannot be
registered in sub–memory.
1 : The machining procedure data can be registered n
sub–memory.
0710 Integer 0 Defined priority on turret during automatic collision prevention
function
0 : Defined by the operator
1 : The turret 1 always has the priority
2 : The turret 2 always has the priority
15–TTF
only
0711 Integer 100 One time override value during outer diameter rough
machining
0712 Integer 1 Magnification of the cutting feedrate when the constant surface
speed is set for balance cut B (Setting range: 1 to 100) If the
value set for the parameter falls outside the setting range, it is
clamped to magnification 1).
0713 to
0728
Integer Undefined Can’t use. (Don’t change the data.)
