Conversional Automatic Programming (CAP) Operators manual Page 168

Operators manual
B–61804E–2/05
3. EXECUTION OF
SYMBOLIC FAPT
PROGRAMMING AND
OPERATION BY SYMBOLIC FAPT
157
(3)Setting an MTF parameter with a number ranging from 1000 to
1999 (16–T CAP II)
No. Format Initial value Description
1392 Character RR Address specifying the difference in the
radius of the thread
1393 Character PP Address specifying the thread height
1394 Character QQ Address specifying the depth of first cut
1395 Character PP Address specifying the tool angle
(Pmmrraa)
1396 Character PP Address specifying the cut method (Not
specified for the FANUC Series 16)
1397 Character RR Address specifying the finishing allowance
(4)Setting MTF parameters with numbers ranging from 2000 to 2999
(Function table, 15TFB)
No. Description Remarks
2060 Block 1 specifying the multiple thread cutting cycle (G76)
2061 Block 2 specifying the multiple thread cutting cycle (G76)
Detail 2060 = 0000, 0000, 0000, 0000, 0000, 0000, 0000, 0000, 0000, 0000,
Multiple thread
2061= 4B02,
G76
1101,
X
0001,
Z
E101,
I
E201,
K
E301,
D
6601,
F
0D03,
A
0F03,
P
0004
;
cu
ng cyc
e
(5)Setting MTF parameters with numbers ranging from 2000 to 2999
(Function table, 16–T CAP II)
No. Description Remarks
2060 Block 1 specifying the multiple thread cutting cycle (G76)
2061 Block 2 specifying the multiple thread cutting cycle (G76)
Detail 2060 = 4B02, 0E03, E401, 0004, 0000, 0000, 0000, 0000, 0000, 0000,
Multiple thread
2061= 4B02,
G76
1101,
X
0001,
Z
E101,
R
E201,
P
E301,
Q
6601,
F
0004,
;
0000, 0000
