Conversional Automatic Programming (CAP) Operators manual Page 256

Operators manual
B–61804E–2/05
2. TOOL DATA AND TOOLING
INFORMATION
SETTING AND DISPLAY OF DATA
249
(Turning tools)
NDDDP__ ; tool management number (ID)
NDDDP__ ; tool type (TP)
NDDDP__ ; tool tip radius/pitch (RN/PT)
NDDDP__ ; cutter angle (AC)
NDDDP__ ; tool tip angle (AN)
NDDDP__ ; tool tip width or drill diameter/tool diameter (WN/DD/DT)
NDDDP__ ; virtual tool tip position (Z–axis)/biting length (ZN/LE)
NDDDP__ ; virtual tool tip position (X–axis)/cutter length (XN/LT)
NDDDP__ ; setting angle (AS)
NDDDP__ ; setting position (Z–axis) (ZS)
NDDDP__ ; setting position (X–axis) (XS)
NDDDP__ ; cutter protective angle (AP)
NDDDP ;
NDDDP ;
NDDDP__ ; working process type 1 (KP1)
NDDDP__ ; working process type 1 (KP2)
NDDDP__ ; working process type 1 (KP3)
NDDDP__ ; tool information (FLAG)
NDDDP__ ; holder number (HL)
Meaning of Tool Information (FLAG)
#7 #6 #5 #4 #3 #2 #1 #0
Bit 0 Tool rest type
0 : ordinaly lathe
1 : X–axis reversible lathe
Bit 3 Spindle rotating direction
0 : forward
1 : reverse
2.3.1
Tool Data Input/Output
Format
