Conversional Automatic Programming (CAP) Operators manual Page 710

Operators manual
APPENDIX
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
60
(i) Arbitrary M, S, T code output
When the significant 1 digit (major classification) is 8, 9, A.
Most significant
3 digits (detailed
classification)
Least significant
1 digit (major
classification)
Function Remarks
M code value 8 M code output
S code value 9 S code output
T code value A T code output
NOTE
With the function codes of major classes 8, 9 and A, the M,
S, T code specified by the first 3 digits of the function code
is output. The value of the M, S, T code to be output is
specified by a 3–digit hexadecimal number.
8: M code
9: S code
0: T code
output M, S, T code value
(hexadecimal number)
Example)
The function code to output S100 is specified as follows.
0649
Indicateds that the address to be
output is S.
Expresses the value to be output
100 in a hexadecimal number.
