Conversional Automatic Programming (CAP) Operators manual Page 416

Operators manual
C–AXIS FAPT FUNCTION
B–61804E–2/05
2. MACHINING DEFINITION
(MENU 4)
150
(Drill)
TOOL TYPE TP; Drill (M)
TOOL MATERIAL MT;. . . . . . . . .
TOOL DIAMETER DT =. . . . . . . . .
CUT LENGTH LT = . . . . . . . . . . . .
NOSE ANGLE AT =. . . . . . . . . . . .
(Tap)
TOOL TYPE TP; Tap (M)
TOOL MATERIAL MT;
TOOL DIAMETER DT =. . . . . . . . .
CUT LENGTH LT = . . . . . . . . . . . .
PECK LENGTH LE =. . . . . . . . . . .
PITCH PT =. . . . . . . . . . . . . . . . . . .
(End mill)
TOOL TYPE TP; End mill (M)
TOOL MATERIAL MT;
TOOL DIAMETER DT =. . . . . . . . .
CUT WIDTH DS =. . . . . . . . . . . . .
CUT LENGTH LT = . . . . . . . . . . . .
CUT COUNT NT =. . . . . . . . . . . . .
Note that the message of tool type (TP) are displayed for 5700 series of
16–T CAP II as follows:
(5700 series)
Center drill (M) C–axis center drill
Drill (M) C–axis drill
Tap (M) C–axis tap
End mill (M) C–axis end mill
NOTE
3 The setting of tool figure data can be disabled, and the data
can be displayed only. To do this, change the following
parameter setting:
No.702: 0 0 0 0 1 0 0 0
Specifies whether tool figure data can be set in m
chining definition.
= 0: Tool figure data cannot be set. (Only the display is enabled.)
= 1: Tool figure data can be set.
Prompts on data of setting (Common to all tool types)
SETTING DIRECTION CP = (0: Side machining, 1: End. . . . .
machining)
SETTING POSITION XS = . . . . . .
ZS =
ROTATE DIRECTION TR = (0: Forwards, 1: Backwards) . . . . .
HOLDER NO. HL = (Note 4). . . . . . . . . . . .
