Conversional Automatic Programming (CAP) Operators manual Page 688

Operators manual
APPENDIX
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
38
Parameter
No.
Description
Initial
value
Format
1034 Integer
4 mm specification
Number of decimal digits of the minimum setting unit of
high
–p
recision screw lead (E code)
6 inch specification
high
–
recision
screw
lead
(E
code)
1035 Integer 3 Number of digits below decimal point of dwell time
1036 Integer 0 Setting of the number of digits below decimal point of S code. Applicable to
S 3–digit and S 4–digit output.
1037 Integer 0 Can’t use. (Don’t change the data.)
1040 2
Characters
ZW Z–axis command address
1st character: Absolute command
2nd character: Incremental command
1041 2
Characters
XU Z–axis command address
1st character: Absolute command
2nd character: Incremental command
1042 2
Characters
KK Circular center address (Designate 2 same characters) in Z–axis direction
1043 2
Characters
II Circular center address (Designate 2 same characters) in X–axis direction
1044 2
Characters
FF Feedrate and thread lead command address (Designate 2 same characters)
1045 2
Characters
EE High–precision thread lead command address
1st character: For normal screw
2nd character: For face screw
1046 2
Characters
UU Dwell command address (Designate 2 same characters)
1047 2
Characters
RR Circular radius R specification address (Designate 2 same characters)
1048 2
Characters
YV Y–axis command address
1st character: absolute command
2nd character: incremental command
1049 2
Characters
JJ Circular center address in Y–axis direction (designate 2 same characters)
1050 Integer 1 Number of turrets (1 or 2)
1 : 2–spindle lathe
2 : 4–spindle lathe (1 spindle/2 turrets)
1051 Integer 1 No.1 turret position
1 : Turret on this side
–1 : Turret on the counter side
1052 Integer 1 No.2 turret position
1 : Turret on this side
–1 : Turret on the counter side
1053 Integer –1 No.1 turret selection M code (–1 is set, if not used)
1054 Integer –1 No.2 turret selection M code (–1 is set, if not used)
