Conversional Automatic Programming (CAP) Operators manual Page 706

Operators manual
APPENDIX
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
56
Most significant
3 digits (detailed
classification)
RemarksFunction
Least significant
1 digit (major
classification)
0 3 0 3 Maximum speed clamp
value S code output
It is output only when the MTF 1085 has the constant
surface speed control function and the constant
surface speed control function is used in the process
parameter (system parameter 0108 – 0114).
0 4 0 3 Surface speed command S
code output
0 5 0 3 F code output It is output only in the case of cutting feed. It is
compared with the modal value and is output only
when it is a different value.
0 6 0 3 Output of program number It is not output when 0 is set to MTF 1080.
0 7 0 3 Final T code output The T code set to the MTF 1106 is output. No output
is made when –1 has been set.
0 8 0 3 Output of subprogram call
P code
The subprogram number (PXXXX) is output by the
subprogram call program (M98PXXXX).
0 9 0 3 R code output For canned cycle
0 A 0 3 Q code output For canned cycle
0 B 0 3 L code output For canned cycle
0 C 0 3 P code output For canned cycle
0 D 0 3 Outputs the address specified in MTF 1395. Tool angle (valid for the Series 15 only)
0 E 0 3 Outputs the address specified in MTF 1395. Tool angle (valid for the Series 16 only)
0 F 0 3 Outputs the address specified in MTF 1396. Specified cut method (valid for the
Series 15 only)
1 0 0 3
F code output Interpolation rigid tapping cycle
Outputs the address
specified in MTF1398
1 1 0 3
T code output Interpolation rigid tapping cycle
Outputs the address
specified in MTF1399
1 2 0 3
B code output
Preparing the tool used in the first process.
Outputs the address
specified in MTF1400.
1 3 0 3
B code output
Preparing the tool used in the next process.
Outputs the address
specified in MTF1400.
1 4 0 3 T code output Output the tool number (TN).
1 5 0 3 T code output Output the tool offset number (TM).
