Conversional Automatic Programming (CAP) Operators manual Page 157

Operators manual
PROGRAMMING AND
OPERATION BY SYMBOLIC FAPT
B–61804E–2/05
3. EXECUTION OF
SYMBOLIC FAPT
146
(3)Edition of the operation sequence
As explained in paragraph “Soft key”, the operation sequence can be
shifted upward or downward by depressing “HEAD 1 UP”, “HEAD
1 DOWN”, “HEAD 2 UP” and “HEAD 2 DOWN”, however, to shift
the operation sequence by this handling is possible during only one
step per operation. Shifting for two steps is not possible. The
operation sequence of turret 1 cannot be transferred to turret 2.
NO HEAD 1 HEAD 2 SPEED
1
ROUGHING OF
OUTER FIGURE.
G96V145M03 (1)
2
ROUGHING OF
INNER FIGURE.
G96V150M03 (2)
3
FINISHING OF
OUTER FIGURE.
G96V200M03 (1)
4
GROOVING G96V100M03 (1)
5
GROOVING
G96V120M03 (2)
If the process editing is executed for the simultaneous
operation of processes 1 and 2, and 4 and 5 the operation is
performed as follows:
NO HEAD 1 HEAD 2 SPEED
1
ROUGHING OF
OUTER FIGURE.
ROUGHING OF
INNER FIGURE.
G97V145M03 (1)
2
3
FINISHING OF
OUTER FIGURE.
G97V200M03 (1)
4
GROOVING
GROOVING
G97V120M03 (2)
5
CAUTION
1 When G96 mode process and G97 mode process are
simultaneously instructed, G97 mode process has priority.
2 If two G96 modes are simultaneously specified, the control
changes to the G97 mode process.
The spindle is controlled by the turret 1 side, but it is
controlled by the turret 2 side when the “S CODE SELECT”
soft key is pressed.
(Example)
