B-63944EN-1/02 PROGRAMMING 4.FUNCTIONS TO SIMPLIFY PROGRAMMING

- 121 -

- Corner R

Second axis on the selected plane → first axis on the selected plane

(G17 plane: Y

→ X

, G18 plane: X

→ Z

, G19 plane: Z

→ Y

)

Format

G17 plane: G01 Y

(V)_ R±r ;

G18 plane: G01 X

(U)_ R±r ;

G19 plane: G01 Z

(W)_ R±r ;

Explanation Tool movement

(U)__

(V)__

(W)__

Specifies movement from

point a to point b with an

absolute or incremental

programming in the figure

on the right.

is the address of the

X-axis of the three basic

axes or an axis parallel to

the X-axis. Y

is the

address of the Y-axis of the

three basic axes or an axis

parallel to the Y-axis. Z

the address of the Z-axis of

the three basic axes or an

axis parallel to the Z-axis.

R±r

Specify the radius of the

arc connecting points d

and c in the figure shown

at right with a sign following

address R.

Moves from a to d and c.

(Positive direction along the first axis

on the selected plane when +r is

specified at R or negative direction

when -r is specified at R)

r r

First axis on

the selected

plane

First axis on

the selected

plane

a Start point
