5.COMPENSATION FUNCTION PROGRAMMING B-63944EN-1/02

- 246 -

NOTE

If a tool offset value is selected as an offset value

to be changed, no offset value change is made for

a travel distance on a rotation axis moved by

follow-up.

Limitation

- Manual operation that cannot change an active offset value

In a mode other than the manual handle feed mode/incremental feed

mode/jog feed mode, no active offset value can be changed.

Moreover, no active offset value can be changed in the manual

reference position return mode.

Even in the modes mentioned above, do not change an active offset

value in the following operations:

• Manual feed for 5-axis machining

• Manual numerical command

• PMC axis control

- Axis that disables an active offset value from being changed

With a rotation axis, no tool offset value can be changed using this

function.

- Offset values that cannot be changed with the active offset value change function

With this function, a tool-noose radius compensation value, B-axis

offset value, and second geometry offset value cannot be changed.
