1.DATA INPUT/OUTPUT OPERATION B-63944EN-1/02

- 354 -

1.2.1 Inputting and Outputting Y-axis Offset Data

With the lathe system, Y-axis offset data can be input and output

using the ALL IO screen.

Inputting Y-axis offset data

Procedure

1 On the ALL IO screen, press the rightmost soft key

(continuous menu key) several times.

2 Press soft key [Y OFFSET].

3 Select EDIT mode.

4 Press soft key [(OPRT)].

5 Press soft key [N READ].

6 Set the name of the file that you want to input.

Type a file name, and press soft key [F NAME].

If the input file name is omitted, default file name

"TOOLOFST.TXT" is assumed.

7 Press soft key [EXEC].

This starts reading the Y-axis offset data, and "INPUT" blinks in

the lower right part of the screen. When the read operation ends,

the "INPUT" indication disappears.

To cancel the input of the program, press soft key [CANCEL].

Outputting Y-axis offset data

Procedure

1 On the ALL IO screen, press the rightmost soft key

(continuous menu key) several times.

2 Press soft key [Y OFFSET].

3 Select EDIT mode.

4 Press soft key [(OPRT)].

5 Press soft key [PUNCH].

6 Set the file name to be output.

Type a file name, and press soft key [F NAME].

If the file name is omitted, default file name "TOOLOFST.TXT"

is assumed.

7 Press soft key [EXEC].

This starts outputting the Y-axis offset data, and “OUTPUT”

blinks in the lower right part of the screen. When the read

operation ends, the “OUTPUT” indication disappears.

To cancel the output, press soft key [CANCEL].
