5.COMPENSATION FUNCTION PROGRAMMING B-63944EN-1/02

- 218 -

- Interference between adjacent three blocks

If an interference is judged to occur between adjacent three blocks, the

interfering vector, as well as any vectors existing inside of it, is erased,

and a path is created to connect the remaining vectors. In the

example shown in the figure below, V

and V

interfere, so that V

and V

are erased, so are V

and V

, which are inside of them, and V

is connected to V

. The operation during this time is linear

interpolation.

Tool center path

Programmed path

If, after vector erasure, the last single vector still interferes, or if there

is only one vector at the beginning and it interferes, an alarm will

occur immediately after the start of the previous block (end point for a

single block) and the tool stops. In the example shown in the figure

below, V

and V

interfere, but, even after erasure, an alarm will occur

because the final vectors V

and V

interfere.

Stopped

Tool center path

Programmed path
