B-63944EN-1/02 PROGRAMMING 6.MEMORY OPERATION BY Series 15 FORMAT

- 307 -

Explanation

- Operations

This cycle performs threading so that the length of the lead only

between C and D is made as specified in the F code. In other

sections, the tool moves in rapid traverse.

The time constant for acceleration/deceleration after interpolation and

FL feedrate for thread chamfering and the feedrate for retraction after

chamfering are the same as for thread chamfering with canned cycle.

CAUTION

Notes on threading are the same as those on G32

threading. For feed hold in a threading cycle,

however, see "Feed hold in a threading cycle"

described below.

- Cutting method

There are four cutting methods.

Tool tip

∆

1st

3rd

2nd

nth

One-edge thread cutting with constant cutting

amount(P1)

Tool ti

Both-edge zigzag thread cutting with constant

cutting amount (P2)

d (finishing allowance)

√

⋅∆

d / 2

d (finishing allowance)

1st

2nd

3rd

4th

5th

6th

∆

√

Fig. 6.4.7 (d) One-edge threading with constant cutting amount, both-edge zigzag threading with constant

cutting amount (P1/2)

∆

d (finishing allowance)

∆

One-edge thread cutting with constant depth of cut

(P3)

d (finishing allowance)

∆

∆d

Both-edge zigzag thread cutting with constant

th of cut

(

)

Tool tip

Fig. 6.4.7 (e) One-edge threading with constant depth of cut, both-edge zigzag threading with constant depth of

cut (P3/4)
