6.MEMORY OPERATION BY Series 15 FORMAT PROGRAMMING B-63944EN-1/02

- 320 -

- Disabling the Series 15 format

The Series 15 command format can be disabled only during a canned

cycle for drilling by setting F16 (bit 3 of parameter No.5102) to 1.

However, the repetitive count must be specified by address L.

CAUTION

If F16 (bit 3 of parameter No.5102) is set to 1, the

settings of RAB (bit 6 of No.5102) and RDI (bit 7 of

No.5102) are disabled, and operation when RAB=0

and RDI=0 is performed.

- Cancel

To cancel a canned cycle, use G80 or a group 01 G code.

Group 01 G codes (Example)

G00 : Positioning (rapid traverse)

G01 : Linear interpolation

G02 : Circular interpolation (CW) or helical interpolation (CW)

G03 : Circular interpolation (CCW) or helical interpolation (CCW)

- Symbols in figures

Subsequent subsections explain the individual canned cycles.

Figures in these explanations use the following symbols:

Positioning (rapid traverse G00)

Cutting feed (linear interpolation G01)

P Dwell
