A.PARAMETERS APPENDIX B-63944EN-1/02

- 404 -

# 4 LGT Tool geometry offset

0: Compensated by the shift of the coordinate system

1: Compensated by the tool movement

NOTE

This parameter is valid when the option for tool

geometry offset or tool wear offset is specified.

# 5 LGC When tool geometry offset is based on a coordinate shift, the

specification of offset number 0:

0: Does not cancel tool geometry offset.

1: Cancels tool geometry offset.

NOTE

This parameter is valid when the option for tool

geometry offset or tool wear offset is specified.

# 6 LWM Tool offset operation based on tool movement is performed:

0: In a block where a T code is specified.

1: Together with a command for movement along an axis.

# 7 WNP Imaginary tool nose number used for tool nose radius compensation,

when the geometry/wear offset function is equipped, is the number

specified by:

0: Geometry offset number

1: Wear offset number
