B-63944EN-1/02 PROGRAMMING 4.FUNCTIONS TO SIMPLIFY PROGRAMMING

- 65 -

4.2.2 Stock Removal in Facing (G72)

This cycle is the same as G71 except that cutting is performed by an

operation parallel to the second axis on the plane (X-axis for the ZX

plane).

Format

ZpXp plane

G72 W(∆d) R(e) ;

G72 P(ns) Q(nf) U(∆u) W(∆w) F(f ) S(s ) T(t ) ;

N (ns) ;

...

N (nf) ;

YpZp plane

G72 V(∆d) R(e) ;

G72 P(ns) Q(nf) V(∆w) W(∆u) F(f ) S(s ) T(t ) ;

N (ns) ;

...

N (nf) ;

XpYp plane

G72 U(∆d) R(e) ;

G72 P(ns) Q(nf) U(∆w) W(∆u) F(f ) S(s ) T(t ) ;

N (ns) ;

...

N (nf) ;

∆d : Depth of cut

The cutting direction depends on the direction AA'. This

designation is modal and is not changed until the other

value is designated. Also this value can be specified by

the parameter (No. 5132), and the parameter is changed

by the program command.

e : Escaping amount

This designation is modal and is not changed until the

other value is designated. Also this value can be

specified by the parameter (No. 5133), and the

parameter is changed by the program command.

ns : Sequence number of the first block for the program of

finishing shape.

nf : Sequence number of the last block for the program of

finishing shape.

∆u : Distance of the finishing allowance in the direction of the

second axis on the plane (X-axis for the ZX plane)

∆w : Distance of the finishing allowance in the direction of the

first axis on the plane (Z-axis for the ZX plane)

f,s,t : Any F , S, or T function contained in blocks ns to nf in

the cycle is ignored, and the F, S, or T function in this

G72 block is effective.

The move command between A and B is specified in the

blocks from sequence number ns to nf.
