4.FUNCTIONS TO SIMPLIFY PROGRAMMING PROGRAMMING B-63944EN-1/02

- 30 -

4.1 CANNED CYCLE (G90, G92, G94)

There are three canned cycles : the outer diameter/internal diameter

cutting canned cycle (G90), the threading canned cycle (G92), and the

end face turning canned cycle (G94).

NOTE

1 Explanatory figures in this section use the ZX plane

as the selected plane, diameter programming for

the X-axis, and radius programming for the Z-axis.

When radius programming is used for the X-axis,

change U/2 to U and X/2 to X.

2 A canned cycle can be performed on any plane

(including parallel axes for plane definition). When

G-code system A is used, however, U, V, and W

cannot be set as a parallel axis.

3 The direction of the length means the direction of

the first axis on the plane as follows:

ZX plane: Z-axis direction

YZ plane: Y-axis direction

XY plane: X-axis direction

4 The direction of the end face means the direction of

the second axis on the plane as follows:

ZX plane: X-axis direction

YZ plane: Z-axis direction

XY plane: Y-axis direction
