5.FUNCTIONS TO SIMPLIFY PROGRAMMING PROGRAMMING B-63944EN-2/02

- 84 -

- Unit of F command

Metric input Inch input Remarks

G94 1 mm/min 0.01 inch/min

Decimal point programming

allowed

G95 0.01 mm/rev 0.0001 inch/rev

Decimal point programming

allowed

- M29

Specifying an S command or axis movement between M29 and G84

causes alarm PS0203.

Then, specifying M29 in the tapping cycle causes alarm PS0204.

- P

Specify P in a block that performs drilling. If P is specified in a

non-drilling block, it is not stored as modal data.

- Cancel

Do not specify a G code of the 01 group (G00 to G03 or G60 (when

the MDL bit (bit 0 of parameter 5431) is set to 1)) and G74 in a single

block. Otherwise, G74 will be canceled.

- Tool offset

In the canned cycle mode, tool offsets are ignored.

- Subprogram call

In the canned cycle mode, specify the subprogram call command

M98P_ in an independent block.

Example

Z-axis feedrate 1000 mm/min

Spindle speed 1000 min

-1

Thread lead 1.0 mm

G94 ; Specify a feed-per-minute command.

G00 X120.0 Y100.0 ; Positioning

M29 S1000 ; Rigid mode specification

G74 Z-100.0 R-20.0 F1000 ; Rigid tapping

G95 ; Specify a feed-per-revolution command.

G00 X120.0 Y100.0 ; Positioning

M29 S1000 ; Rigid mode specification

G74 Z-100.0 R-20.0 F1.0 ; Rigid tapping
