6.COMPENSATION FUNCTION PROGRAMMING B-63944EN-2/02

- 108 -

NOTE

1 When an H code is specified in the same block as

G37, an alarm is generated. Specify H code before

the block of G37.

2 The measurement speed (FP), γ, and ε are set as

parameters (FP: No. 6241, γ: No. 6251, ε: No.

6254) by the machine tool builder. Make settings

so that e are always positive and γ are always

greater than ε.

3 When offset memory A is used, the offset value is

changed. When offset memory B is used, the tool

wear compensation value is changed. When offset

memory C is used, the tool wear compensation

value for the H code is changed.

4 A delay or variation in detection of the

measurement position arrival signal is 0 to 2 msec

on the CNC side excluding the PMC side (0.1 msec

or less for high-speed measurement position arrival

signal input (optional)). Therefore, the

measurement error is the sum of 2 msec and a

delay or variation (including a delay or variation on

the receiver side) in propagation of the skip signal

on the PMC side, multiplied by the feedrate set in

parameter No. 6241.

5 A delay or variation in time after detection of the

measurement position arrival signal until a feed

stops is 0 to 8 msec. To calculate the amount of

overrun, further consider a delay in

acceleration/deceleration, servo delay, and delay

on the PMC side.
