B-63944EN-2/02 PROGRAMMING 2.PREPARATORY FUNCTION (G FUNCTION)

- 17 -

Table 2(a) G code list

G code Group Function

G66 Macro modal call A

G66.1 Macro modal call B

G67

Macro modal call A/B cancel

G68 Coordinate system rotation start or 3-dimensional coordinate conversion mode on

G69 Coordinate system rotation cancel or 3-dimensional coordinate conversion mode off

G68.2

Feature coordinate system selection

G72.1 Figure copy (rotation copy)

G72.2

Figure copy (linear copy)

G73 Peck drilling cycle

G74 Left-handed tapping cycle

G76 Fine boring cycle

G80

Canned cycle cancel

G80.5 24 Electronic gear box 2 pair: synchronization cancellation

G80.8 34 Electronic gear box: synchronization cancellation

G81 09 Drilling cycle or spot boring cycle

G81.1 00 Chopping

G81.5 24 Electronic gear box 2 pair: synchronization start

G81.8 34 Electronic gear box: synchronization start

G82 Drilling cycle or counter boring cycle

G83 Peck drilling cycle

G84 Tapping cycle

G84.2 Rigid tapping cycle (FS15 format)

G84.3 Left-handed rigid tapping cycle (FS15 format)

G85 Boring cycle

G86 Boring cycle

G87 Back boring cycle

G88 Boring cycle

G89

Boring cycle

G90 Absolute programming

G91

Incremental programming

G91.1 Checking the maximum incremental amount specified

G92 Setting for workpiece coordinate system or clamp at maximum spindle speed

G92.1

Workpiece coordinate system preset

G93 Inverse time feed

G94 Feed per minute

G95

Feed per revolution

G96 Constant surface speed control

G97

Constant surface speed control cancel

G98 Canned cycle : return to initial level

G99

Canned cycle : return to R point level

G107 00 Cylindrical interpolation

G112 Polar coordinate interpolation mode

G113

Polar coordinate interpolation mode cancel
