A.PARAMETERS APPENDIX B-63944EN-2/02

- 312 -

8375 Maximum chopping feedrate

[Input type] Parameter input

[Data type] Real axis

[Unit of data] mm/min, inch/min, deg/min (machine unit)

[Minimum unit of data] Depend on the increment system of the applied axis

[Valid data range] Refer to the standard parameter setting table (C)

(When the increment system is IS-B, 0.0 to +240000.0)

The chopping feedrate is clamped to the setting of this parameter.

When this parameter is set to 0 for the chopping axis, the chopping

feedrate is clamped to the rapid traverse rate (parameter No. 1420).

8376 Chopping compensation factor

[Input type] Parameter input

[Data type] Byte path

[Unit of data] %

[Valid data range] 0 to 100

The value obtained by multiply the sum of the servo delay in an

chopping operation and the acceleration/deceleration delay by the rate

set in this parameter is used as chopping delay compensation. When

this parameter is set to 0, chopping delay compensation is not applied.

8377 Chopping compensation start tolerance

[Input type] Parameter input

[Data type] 2-word path

[Unit of data] Detection unit

[Valid data range] 0 to 99999999

In a chopping operation, compensation is applied when the difference

between an amount of shortage at the upper dead point and that at the

lower dead point due to the servo position control delay is less than

the value set in this parameter. When this parameter is set to 0,

compensation is not applied.

#7 #6 #5 #4 #3 #2 #1 #0

19607

NAA CAV CCC

[Input type] Parameter input

[Data type] Bit path

# 2 CCC In the cutter or tool nose radius compensation mode, the outer corner

connection method is based on:

0: Linear connection type.

1: Circular connection type.
