FANUC Series 30i/31i/32i -A, 31i -A5

CANNED GRINDING CYCLE

(FOR GRINDING MACHINE)

Explanations

The intermittent-feed surface grinding cycle consists of six operation sequences.

Operations (1) to (6) are repeated until the depth reaches the total depth of cut specified with

address K. In the single block stop mode, operations (1) to (6) are performed at a time by one

cycle start.

• Operation sequences in the cycle

(1) Grinding wheel cutting

Cutting is performed along the Z-axis in cutting feed mode to the amount specified by I

(depth of cut 1). The feedrate is specified by R.

(2) Dwell

Dwell is performed for the time specified by P.

(3) Grinding

Cutting feed is performed for the amount specified by α. The grinding axis is selected by the

parameter No.5179. The feedrate is specified by F. When address L is specified while the

continuous dressing function is valid, dressing is performed by the cutting axis and the

dressing axis. The dressing axis is selected by the parameter No.5183.

(4) Grinding wheel cutting

Cutting is performed along the Z-axis in cutting feed mode for the amount specified by J

(depth of cut 2). The feedrate is specified by R.

(5) Dwell

Dwell is performed for the time specified by P.

(6) Grinding (return direction)

Cutting feed is performed in the reverse direction to the amount specified by α at a feedrate

specified by F. When address L is specified while the continuous dressing function is valid,

dressing is performed by the cutting axis and the dressing axis.

• Continuous dressing

When the continuous dressing function is valid and during grinding, grinding wheel cutting

and dresser cutting are compensated continuously according to the dressing amount specified

by L. For the details, refer to the explanations of G75.
