B-63944EN-2/02 APPENDIX A.PARAMETERS

- 295 -

5163

M code that specifies the peck drilling cycle mode of a small diameter

[Input type] Parameter input

[Data type] 2-word path

[Valid data range] 1 to 99999999

This parameter sets an M code that specifies the peck drilling cycle

mode of a small diameter.

5164

Percentage of the spindle speed to be changed at the start of the next

advancing after an overload torque detection signal is received

[Input type] Parameter input

[Data type] Word path

[Unit of data] %

[Valid data range] 1 to 255

This parameter sets the percentage of the spindle speed to be changed

at the start of the next advancing after the tool is retracted because the

overload torque detection signal is received.

S2 = S1 × d1 ÷ 100

S1: Spindle speed to be changed

S2: Spindle speed changed

Set d1 as a percentage.

NOTE

When 0 is set, the spindle speed is not changed.

5165

Percentage of the spindle speed to be changed at the start of the next

advancing when no overload torque detection signal is received

[Input type] Parameter input

[Data type] Word path

[Unit of data] %

[Valid data range] 1 to 255

This parameter sets the percentage of the spindle speed to be changed

at the start of the next advancing after the tool is retracted without the

overload torque detection signal received.

S2 = S1 × d2 ÷ 100

S1: Spindle speed to be changed

S2: Spindle speed changed

Set d2 as a percentage.

NOTE

When 0 is set, the spindle speed is not changed.
