6.COMPENSATION FUNCTION PROGRAMMING B-63944EN-2/02

- 104 -

CAUTION

1 Specifying tool length compensation (a shift type)

first and then executing an incremental

programming causes the tool length compensation

value to be reflected in the coordinates only, not in

the travel distance of the machine; executing an

absolute programming causes the tool length

compensation value to be reflected in both the

movement of the machine and the coordinates.

2 If a programmable mirror image is effective, the tool

length compensation is applied in the specified

direction.

3 No scaling magnification is applied to the tool length

compensation value.

4 No coordinate system rotation is applied to the tool

length compensation value. Tool length

compensation is effective in the direction in which

the offset is applied.

5 The tool length compensation operation is

independent of the cutter compensation offset

operation.

6 Three-dimensional coordinate conversion is applied

to tool length compensation. If tool length

compensation is made effective to multiple axes,

the tool length compensation must be canceled for

one axis at a time.

7 With the WINDOW command, changing parameter

TOS during automatic operation does not cause the

tool length compensation type to be changed.

8 If offset has been performed on two or more axes

with tool length compensation B, a G49 command

causes the offset to be canceled on all axes; H0

causes the offset to be canceled only on the axis

vertical to the specified plane.

9 If the tool length compensation value is changed by

changing the offset number, this simply means that

the value is replaced by a new tool length

compensation value; it does not mean that a new

tool length compensation value is added to the old

tool length compensation.
