B-63944EN-2/02 APPENDIX A.PARAMETERS

- 291 -

#7 #6 #5 #4 #3 #2 #1 #0

AON

5041

[Input type] Parameter input

[Data type] Bit path

# 6 AON If a change is made to a tool compensation value (tool length

compensation value used with tool length compensation A/B in the

case of the M series):

0: In the case of the M series, the change becomes effective starting

with the next block specifying G43, G44, or an H code.

In the case of the T series, the change becomes effective starting

with the next block specifying a T code.

1: The change becomes effective starting with the next block to be

buffered.

NOTE

1 This parameter is valid when bit 6 (EVO) of

parameter No. 5001 is set to 0.

2 The operation of this parameter set to 1 is valid

even if a new compensation value is further

changed by MDI input or a G10 command before

the new compensation value becomes effective.

3 The operation of this parameter set to 1 is invalid if

a reset operation is performed before a new

compensation value becomes effective.

#7 #6 #5 #4 #3 #2 #1 #0

5042 OFE OFD OFC OFA

[Input type] Parameter input

[Data type] Bit path

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

# 0 OFA

# 1 OFC

# 2 OFD

# 3 OFE These bits are used to specify the increment system and valid data

range of a tool offset value.

For metric input

OFE OFD OFC OFA Unit Valid data range

0 0 0 1 0.01mm ±9999.99mm

0 0 0 0 0.001mm ±9999.999mm

0 0 1 0 0.0001mm ±9999.9999mm

0 1 0 0 0.00001mm ±9999.99999mm

1 0 0 0 0.000001mm ±999.999999mm
