B-63944EN-2/02 PROGRAMMING 3.INTERPOLATION FUNCTION

- 25 -

Inward offset

OVR = Rcp/(Rcp + Rofs) × 100

Outward offset

OVR = Rcp/(Rcp - Rofs) × 100

where,

Rcp : Radius of curvature at the center of the tool of the

involute curve passing through the center of the tool

Rofs : Radius of the cutter

- Clamping the override

The lower limit of override is specified in parameter No. 5620 so that

the override for inward offset by cutter compensation or the override

in the vicinity of the basic circle will not bring the speed of the tool

center to zero in the vicinity of the basic circle.

The lower limit of override (OVR1o) is specified in parameter No.

5620 so that the inward offset will not reduce the speed of the tool

center to a very low level in the vicinity of the basic circle.

Accordingly, the feedrate is clamped but does not fall below the level

determined by the programmed feedrate and the lower limit of

override (OVR1o).

The outward offset may increase the override to a very high level, but

the feedrate will not exceed the maximum cutting feedrate.

- Clamping the acceleration in the vicinity of basic circle

If the acceleration calculated from the radius of curvature of the

involute curve exceeds a value specified in the corresponding

parameter, the tangential velocity is controlled so that the actual

acceleration will not exceed the value specified in the parameter.

Because the acceleration is always limited to a constant level, efficient

velocity control can be performed for each machine. Because

smooth velocity control can be performed continuously, impacts in

machining in the vicinity of the basic circle can be reduced.

To calculate the acceleration, the radius of curvature of the involute

curve and the tangential velocity are substituted into the following

formula of circular acceleration:

Acceleration = F × F/R

F: Tangential velocity

R: Radius of curvature

The maximum permissible acceleration is specified in parameter No.

1735.

If the calculated acceleration exceeds the maximum permissible

acceleration, the feedrate is clamped to the level calculated by the

following expression:

onaccelerati epermissibl Maximum curvature of Radius level Clamp ×=

If the calculated clamp level falls below the lower limit of feedrate,

the lower limit of feedrate becomes the clamp level. The lower limit

of feedrate is specified in parameter No. 1732.
