5.FUNCTIONS TO SIMPLIFY PROGRAMMING PROGRAMMING B-63944EN-2/02

- 70 -

- Auxiliary function

When the G88 command and an M code are specified in the same

block, the M code is executed at the time of the first positioning

operation. When K is used to specify the number of repeats, the M

code is executed for the first hole only; for the second and subsequent

holes, the M code is not executed.

- Tool length compensation

When a tool length compensation (G43, G44, or G49) is specified in

the canned cycle for drilling, the offset is applied after the time of

positioning to point R.

Limitation

- Axis switching

Before the drilling axis can be changed, the canned cycle for drilling

must be canceled.

- Drilling

In a block that does not contain X, Y, Z, R, or any other axes, drilling

is not performed.

- P

Specify P in blocks that perform drilling. If it is specified in a block

that does not perform drilling, it cannot be stored as modal data.

- Cancel

Do not specify a G code of the 01 group (G00 to G03) and G88 in a

single block. Otherwise, G88 will be canceled.

- Tool offset

In the canned cycle mode for drilling, tool offsets are ignored.

Example

M3 S2000 ; Cause the spindle to start rotating.

G90 G99 G88 X300. Y-250. Z-150. R-100. P1000 F120. ;

Position, drill hole 1, return to point R then stop

at the bottom of the hole for 1 s.

Y-550. ; Position, drill hole 2, then return to point R.

Y-750. ; Position, drill hole 3, then return to point R.

X1000. ; Position, drill hole 4, then return to point R.

Y-550. ; Position, drill hole 5, then return to point R.

G98 Y-750. ; Position, drill hole 6, then return to the initial

level.

G80 G28 G91 X0 Y0 Z0 ; Return to the reference position

M5 ; Cause the spindle to stop rotating.
