B-63944EN-2/02 APPENDIX A.PARAMETERS

- 297 -

5168

Lower limit of the percentage of the cutting feedrate in a peck drilling cycle o

a small diameter

[Input type] Parameter input

[Data type] Byte path

[Unit of data] %

[Valid data range] 1 to 255

This parameter sets the lower limit of the percentage of the cutting

feedrate changed repeatedly to the specified cutting feedrate.

FL = F × b3 ÷ 100

F: Specified cutting feedrate

FL: Changed cutting feedrate

Set b3 as a percentage.

5170

Number of the macro variable to which to output the total number of

retractions during cutting

[Input type] Parameter input

[Data type] Word path

[Valid data range] 100 to 149

This parameter sets the number of the custom macro common variable

to which to output the total number of times the tool is retracted

during cutting. The total number cannot be output to common

variables #500 to #599.

5171

Number of the macro variable to which to output the total number of

retractions because of the reception of an overload torque detection signal

[Input type] Parameter input

[Data type] Word path

[Valid data range] 100 to 149

This parameter sets the number of the custom macro common variable

to which to output the total number of times the tool is retracted after

the overload torque detection signal is received during cutting. The

total number cannot be output to common variables #500 to #599.
